The new Q is small enough to fit in your palm. Its capabilities, on the other hand, are enormous. The Q has complete aperture and shutter control. Both RAW and JPEG processing. And the smallest interchangeable lens system in the world, including a standard prime, zoom, fish-eye and the unique "toy" wide angle and telephoto lenses.
The Q captures amazingly sharp images and HD video, thanks to an innovative 12.4 megapixel sensor with an advanced backlit design. Since the circuitry is behind the photo diode, unlike typical CMOS sensors, the Q gathers more light in a small area for outstanding low light performance and low noise. The sensor was also designed for motion video, capturing your memories at full 1080p resolution with the versatile h.264 compression.
With the highly adaptable Q, you have complete creative freedom. Its many modes let you apply multiple image effects - from brilliant and vintage color to warm fade and bold monochrome. Other modes allow you to save favorite camera settings, filters and custom image modes for instant reuse.
Start with a white or black magnesium alloy body. Choose your interchangeable lenses. Add external options such as a shoe-mounted viewfinder, lens hoods and filters. And capture it all with the PENTAX Q.
Introducing the PENTAX Q, the world’s smallest, lightest interchangeable lens camera with a tiny body and a 12.4 megapixel CMOS image sensor that carves out an entirely new camera category.
View Demo
Capture stabilized, blur and dust free images even in low lighting courtesy of the Q’s sensor-shift Shake Reduction system with integrated DRII Dust Reduction. Body-based Shake Reduction operates independently of the Q’s lenses, allowing the same level of stabilization regardless of lens selection.
Compose images and video either with the Q’s LCD monitor or using a shoe-mounted viewfinder attachment available as an optional accessory. The External Viewfinder O-VF1 makes an excellent accessory to the Q, offering outstanding compositional framing, even in the brightest sunlight where viewing an LCD screen is traditionally a challenge.
The Q represents an evolution in interchangeable lens digital camera design, featuring the world’s smallest and lightest body. Experience the PENTAX Q. The Camera. Evolved.
Enjoy exceptional image quality in 12.4 megapixels courtesy of the Q’s 1/2.3 inch backlit CMOS image sensor. Capable of producing 12 bit DNG RAW and JPG images, the backlit CMOS sensor is a highly efficient light-gathering instrument designed specifically to produce very low noise at high levels of sensitivity.
Experienced photographers will enjoy the power and flexibility of traditional DSLR shooting modes such as Program, Aperture/Shutter Priority, and Metered Manual exposure control. Yet casual shooters will appreciate the highly convenient automatic modes such as the set-it-and-forget-it PENTAX Auto Picture and 21 scene modes.
In-camera HDR capture mode shoots 3 images of varying exposures, blending them to bring out the details in even the darkest shadows and brightest highlights of extreme contrast shots.
Easily capture or review images and video using the Q’s large 3 inch LCD monitor. The high quality LCD features HVGA resolution with 460,000 dots, as well as viewing angles up to 170 degrees horizontally and vertically.
Enjoy effortless bokeh control with the Q’s bokeh control filter. Traditionally controlled through a DSLR lens’s aperture, bokeh is the out of focus part of the background that helps to emphasize the subject, drawing the viewer’s eyes to the most important part of the photo. The Q assists the experienced and casual photographer alike by offering a fine degree of extra control over image bokeh via an in-camera filter operation.
Powerful USER modes allow the creative photographer to save a series of favorite camera settings, filters, and custom image modes for instant reuse.
The Q’s built-in popup flash adds the perfect amount of extra light to an image, while its high extension naturally reduces the redeye effect common to compact cameras. The Q’s flash is effective to 23 feet at 200 ISO, and covers a wide angle 28 degree field of view.
The Q is compatible with the latest generation SD, SDHC, and SDXC memory cards for ultra-high capacity storage as well as outstanding image file portability.
The Q features the newly designed PENTAX Q-mount lens system for convenient interchangeability with a variety of specialty Q lenses. Choose from a selection of prime, zoom, fisheye lenses, and more to suit just about any photographic need. The Q system will be available in a standard kit that includes the 8.5mm lens (equivalent to 47mm).
Though extremely compact, the Q is also surprisingly durable, sporting lightweight, scratch resistant magnesium alloy body.
Conveniently choose from a variety of creative modes, Smart Effect options, or camera settings to assign to the Q’s Quick Dial located on the front of the camera. Easily customize the setting or effect using the Quick Dial’s 4 positions, allowing you to concentrate on photography without having to explore the camera’s menu system.
Shoot high quality motion video with stunning full 1080p HD clarity at 30 frames per second. The Q efficiently processes the full HD video using high quality h.264 compression for superior color and detail. Explore creative video effects through the use of custom image modes, digital video filters, and interval shooting; or select from a variety of Q lenses to realize your perfect artistic vision.
Capture even the fastest action with a 5 frames per second continuous shooting mode, ideal for sporting events, children at play, or any fast action situation.
New Smart Effects modes enhance digital photography by applying a series of effects to images to achieve high quality finishing. Brilliant Color, Vintage Color, Warm Fade, Bold Monochrome, and Water Color are just some of the Smart Effects available, which can also be assigned to the Q’s Quick Dial.
Shutter speeds range from 1/2000 to 30 seconds, perfect for freezing fast action or capturing long nighttime exposures. Bulb mode adds flexibility for low light photography and motion effects.
A built-in micro HDMI port is perfect for outputting high resolution images and video, with sound, to modern HDTVs.
The Q includes SILKYPIX Developer Studio 3 software for powerful and flexible RAW file processing. In-camera RAW image development is also supported.
Type | Digital Hybrid |
Sensor | Type: Backlit CMOS w primary color filter and integrated Shake/Dust Reduction sensor-shift system Size: 1/2.3” Color depth: 8 bits/channel JPG, 12 bits/channel RAW Effective pixels: 12.4M Total pixels: 12.75M Recorded resolutions Still 4:3: 12M (4000x3000), 9M (3456x2592), 5M (2688x2016), 3M (1920x1440) Still 3:2: 10M (4000x2664), 8M (3456x2304), 5M (2688x1792), 2M (1920x1280) Still 16:9: 9M (4000x2248), 6M (3456x1944), 4M (2688x1512), 2M(1920x1080) Still 1:1: 9M (2992x2992), 6M (2592x2592), 4M (2016x2016), 2M (1440x1440) Movie (resolution/FPS): 1920x1080p30, 1280x720p30, 640x480p30 Quality levels: *** Best, ** Better, * Good Dust Removal: DRII (ultrasonic vibration to low pass filter) |
Lens | Type/construction: PENTAX Q-mount bayonet stainless steel mount |
Focus System | Type: TTL Contrast Detection AF |
Viewfinder | Type: n/a (optional shoe mounted optical viewfinder O-VF1 available for 01 Standard Prime lens) |
LCD Monitor | Type: 3.0” TFT color LCD Resolution: HVGA 460,000 dots Wide angle viewable: Yes, approx 170° horizontal and vertical LIVE VIEW Type: TTL by CMOS image sensor Field Of View: 100% Display Modes: Grid (4x4, Golden Ratio, Scale), Bright/Dark Indication, Histogram |
Flash | Type: P-TTL flash with retractable popup extension |
External Flash | Type: Hotshoe P-TTL |
Storage Media | Internal memory: n/a |
Interfaces | Ports: USB 2.0 hi-speed, AV out, HDMI out (Type D, Micro) |
Power Supply | Power source: Rechargeable Li-Ion battery D-LI68 |
Physical Specs | Body dimensions (W x H x D): 3.9 x 2.3 x 1.2” Body weight Without battery or removable memory: 6.3 oz Loaded and ready: 7.1 oz Construction material(s): Magnesium alloy shell Weather resistant: n/a Operating temperature: 32-104°F |
Language Support | English, French, German, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Russian, Korean, Traditional & Simplified Chinese, Japanese |
Image Stabilization | Type: Sensor Shift Shake Reduction (4 stops max) |
Metering System | Type: TTL image sensor metering Sensitivity range: EV 1.3-17.0 (ISO 125, F1.9), +2 EV w electronic shutter or ND filter Multi-segment: Yes Center weighted: Yes Spot: Yes Exposure compensation: +/- 3 EV (1/3 steps) Exposure lock: Yes (via half shutter press, can also be assigned to Green button) Exposure bracketing: Yes (3 frames, up to +/- 3 EV in 1/3 or 1/2 steps, remote enabled) |
ISO Sensitivity | Auto: ISO 125-6400 (1/3 steps), Bulb mode up to ISO 1600, auto ISO range selectable Manual: ISO 125-6400 (1/3 steps), Bulb mode up to ISO 1600 |
White Balance | Auto preset modes: Auto, Daylight, Shade, Cloudy, Fluorescent (D, N, W, L), Tungsten, Flash, CTE Manual mode(s): Yes * WB fine adjustment available in all modes |
Shutter | Type: Lens shutter, electronic shutter** Shutter speed: 1/2000 to 30 sec (lens shutter), 1/8000 to 30 sec (electronic shutter w a lens shutter lens), Bulb ** When using the electronic shutter setting with a non-lens shutter lens, shutter speed 1/8000 to 2 sec, Bulb, aperture adjustment, and ND filter setting NA. |
Capture Modes | Mode selection: Auto Picture, Scene, Program (P), Shutter Priority (Tv), Aperture Priority (Av), Metered Manual (M), Blur Control (BC, JPG only), Movie, Bulb (available in Metered Manual) Auto Picture modes: Standard, Portrait, Landscape, Macro, Night Scene Portrait, Night Scene, Blue Sky, Forest Scene modes: Portrait, Landscape, Macro, Moving Object, Night Scene Portrait, Sunset, Blue Sky, Night Scene, Night Scene HDR (JPG only), Night Snap, Food, Quick Macro (JPG only), Pet, Kids, Forest, Surf & Snow, HDR (JPG only), Backlight Silhouette, Candlelight, Stage Lighting, Museum Custom Image modes: Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Bleach Bypass, Reversal Film, Monochrome (including film filters, infrared, sepia toning), Cross Processing (creative random effect generation). Smart Effects: Brilliant Color, Unicolor Bold, Vintage Color, Cross Processing, Warm Fade, Tone Expansion, Bold Monochrome, Watercolor, Vibrant Color Enhance, USER 1-3 Green simplified mode available: Yes Face detection available: Yes P/A/S/M/B: P, A, S, M, B (in Metered Manual) Date stamp: n/a Digital filters (capture): Toy Camera, High Contrast, Shading, Slim, HDR, Invert Color, Extract Color, Color, Watercolor, Posterization, Fisheye Dynamic Range adjustment: Yes (highlight and shadow correction) File/Folder customization: Folder name (standard/date) |
Drive Modes | Mode selection: Single, Continuous (Hi, Lo), Self Timer (12s, 2s), Infrared Remote (0s, 3s, continuous), Auto Bracketing (3 frames, up to +/- 3 EV in 1/3 or 1/2 steps, remote enabled) Continuous FPS: Approx 5 FPS (Continuous Hi: 5 JPG), 1.5 FPS (Continuous Lo: 100 JPG) Multi-exposure: Yes (2-9 shots, auto exposure adjustment) Interval: Yes (1s to 24h, up to 999 shots, delayed start available) HDR: Auto, HDR1, HDR2 (HDR blended images saved in JPG only) |
Playback Modes | Mode selection: One Shot, Multi Image Display (4, 9, 20, 42, 90 thumbnails), Magnification (up to 16X, scrollable, quick zoom), Histogram, Folder, Calendar Filmstrip, Select & Delete, Movie Playback, Bright/Dark Indication, Slideshow Mode pallet: Image Rotation, Digital Filter, Redeye Edit, Resize, Cropping, Index, Protect, Slideshow, Cross Processing, RAW Development, Movie Edit, Image Comparison, DPOF Digital filters (playback): Monochrome, Toy Camera, High Contrast, Shading, Slim, HDR, Invert Color, Extract Color, Color, Watercolor, Posterization, Fisheye, Retro, Soft, Sketch, Miniature, Frame Composite, Starburst, Base Param Adj Movie edit: Movie Divide, Delete Frames |
File Formats | Still: RAW (DNG), JPG (EXIF 2.3), DCF 2.0, DPOF, PIM III Movie (compression): MP4 (AVC h.264) |
Custom Functions | Functions available: 13 |
Computer Requirements | *For direct device connectivity. Bundled software requirements may vary. Windows: Windows XP SP3 (32 bit), Vista & 7 (32 & 64 bit), USB port Mac: MacOS 10.3.9, 10.4, 10.5, 10.6, USB port |
